Target holes were first seen in the lamination process of PCB multilayer circuit boards. In recent years, for the positioning holes that need to be positioned and processed, everyone is generally called the target hole. The branch links are reduced with the integrated design concept, and the modular structure design is cleverly adopted along the integrated design concept to achieve seamless connection between modules. The composition of the entire structure is reasonable and compact, the modules are harmoniously matched with each other, the combination is firm, the movement is smooth, and there is no reverse backlash. Thereby creating the superior performance of the equipment, with excellent quality of fast speed, high precision, low noise and good stability.

1. All equipment is CE certified. And can be customized to meet customer requirements of other certification.

2. Our equipment is highly automated, and one person can man multiple production lines.

3. Accept OEM/ODM, screen printing industry whole line customization.

4. Printing, punching, die cutting precision 0.02mm.CCD camera visual alignment system, fast and accurate positioning and fine tuning, to ensure accuracy requirements.

Punch Configuration and Features

In the hardware control system, Japan's special motion control chip is used, and the curve acceleration scheme is adopted to make the machine operate with high speed and low vibration, thereby improving the operating efficiency of the machine and the service life of the machine. The German Bagra stepper motor is used, which has low noise, fast running speed, and especially accurate positioning, which is a necessary condition to ensure the accuracy of the equipment. Using Japan's Sony industrial CCD high-definition black and white image sensor, the scanning rate is as high as 100 frames per second, which lays a strong foundation for high-speed image capture. Using the US II-VI optical lens, the curvature of light is very small, which ensures the clarity and fidelity of the image, which is a prerequisite for ensuring the accuracy of the equipment. The software control system is developed by our engineers with the help of years of in-depth research on computer graphics, combined with practice, and through repeated verification in practice. The program code is logically well thought out, has high execution efficiency, and has strong intelligent analysis capabilities. It can effectively discard the fake and save the real graphics entering the CCD camera field of view, compare and confirm samples, and has the advantages of fast recognition speed, high resolution ability, and bullseye. Identify salient features such as accuracy. The equipment intelligently controls the retraction stroke of the die to ensure that the upper and lower ends of the die do not touch the bottom during the stamping process, thereby eliminating the harsh impact sound when the die is stretched and reaching the top, realizing the mute effect of the equipment and making the equipment more humane change.

Application

Punching for below sheet materials:
Membrane switch, conductive film, IMD/IML/PET/PVC film, FPC flexible board, label, sticker, PC, panel, aluminum plate, aluminum substrate, Car nameplate,etc

Parameters

Packing remark:

The Automatic CCD alignment hole punching machine will be packed in strict safety before transportation.As shown in the figure above.Try to ensure that no damage occurs in the course of transportation.

Due to the large size and heavy mass of the printing equipment, we generally use sea or road transport for transportation. You can choose to transport by sea route or by China-Europe Railway Express. As for the terms of trade, we usually adopt EXW,FOB or CIF.

The specific way can be confirmed in the process of communication and confirmation of the order
